To meet various design requirements, three different luminaire covers are available. These are based on a particularly slender standard ring with a recess for the reflector. The reflector has a returned edge that covers the narrow mounting ring, thereby forming a design feature. The interchangeable ring system is highly versatile and consists of an easy-to-assemble base ring that can be fitted with many different accessories. |
|
|
|
|
Standard one-piece, narrow, luminaire cover frame. The reflector edge sits in a slight recess and finishes flush with the surface.
Standard one-piece, narrow, luminaire cover frame. The reflector edge sits in a slight recess and finishes flush with the surface.
2-part interchangeable ring system. The luminaire is supplied with a fixed frame. A separate cover frame is secured with a bayonet fixing. Also suitable for retro-fitting photo-optic accessories.
|
|
Cast-in housings for concrete
The use of concrete fittings makes it possible to integrate recessed luminaires harmoniously into ceilings. Custom adaptations also enable special static specifications to be satisfied. This includes lengthened inlet ports to allow rebar to be routed underneath the fitting. To suit the ceiling situation, the fittings available are either flat and angular or narrow and round with greatly reduced volume. When using round cast-in housings, specially adapted downlights with electronic control gear mounted on them must be used.
 |
